Diwali night, family WhatsApp group

Fifty-three relatives in "Sharma Family 🪔". Mummy sends a photo of diyas. Chacha forwards a Good Morning meme from 2019. Your cousin in Toronto replies at 3 AM his time. Nani types "happy diwali beta" without punctuation. Messages arrive out of order sometimes. Blue ticks appear. Someone sends a voice note. The group never sleeps.

That is a chat system. Not email. Not a news feed. Real-time (or near-real-time) messaging with delivery states, 1:1 and group conversations, and the expectation that if you sent it, the other person will see it — even if they were offline.

This chapter covers the core: message flow, WebSocket vs polling, schema, delivery states. No gateway clusters, no presence at scale. Lesson 22.

Diwali family WhatsApp group chaos

Fifty-three relatives. One group. Zero punctuation from Nani.

Chat system architecture

Blue ticks are a distributed systems problem wearing a UX costume.

Requirements — functional and non-functional

Functional

1:1 chat — two users exchange messages in a private conversation
Group chat — N users in one conversation (family group, office team)
Message history — scroll up to see older messages
Delivery states — sent ✓, delivered ✓✓, read ✓✓ (blue)
Offline support — messages queue and deliver when user comes back
Optional: media, typing indicators, reply-to (mention, do not over-build)

Non-functional

Delivery latency — < 100 ms for online recipients; feels instant
Message ordering — mostly chronological per conversation; perfect global order not required
Durability — once server ACKs send, message must not be lost
Scale hint: write-heavy during festivals; 1:1 is symmetric, groups fan out

Clarify: WhatsApp-scale or startup MVP? I commit to text messages, 1:1 + group, three delivery states. Skip E2E encryption implementation unless asked — mention it exists in production.

Clarifying with the interviewer

You: "1:1 and group chat both in scope?"
     -> Interviewer: "Yes, group up to 256 members."

You: "Real-time delivery — WebSocket acceptable?"
     -> Interviewer: "Yes."

You: "Do we need read receipts and delivery ticks?"
     -> Interviewer: "Yes, like WhatsApp."

You: "Offline messages — store and deliver on reconnect?"
     -> Interviewer: "Yes."

You: "I will cover send/store/deliver flow, schema, WebSocket
     transport, and delivery state machine. Scale in follow-up."

1:1 vs group chat

1:1 conversation:

Exactly two participants
Message sent once, delivered to one recipient
Simple routing: recipient_id known at send time

Group conversation:

N participants (cap at 256 for MVP — WhatsApp limit)
Message sent once, fan-out to N-1 other members
Each member has own delivery/read state per message

Group chat is a mini news feed fan-out inside one room. Same push pattern, smaller N. Diwali family group with 53 members is manageable synchronously; 256-member office group needs async fan-out.

WebSocket vs long polling

Client needs server-initiated delivery — HTTP request/response alone cannot push.

Long polling

Client: GET /messages/poll?since=msg_123
Server: holds connection open up to 30 sec
        if new message → return immediately
        else → return empty, client reconnects

Pros: works through corporate firewalls, no special protocol

Cons: high connection churn, latency spikes, wasteful on mobile battery

WebSocket (recommended)

Client: WS connect wss://chat.schoolabe.com/ws?token=...
Server: persistent bidirectional channel
Client sends: { "type": "send", "conversation_id": "...", "body": "..." }
Server pushes: { "type": "message", "payload": { ... } }

Pros: low latency, single connection, efficient for mobile

Cons: load balancer sticky sessions or connection registry at scale (Lesson 22)

Interview pick: WebSocket for real-time chat. Mention long polling as fallback for restrictive networks. Nobody designs WhatsApp on long polling in 2026.

Message flow: send → store → deliver

The happy path for 1:1 chat:

1. Sender types message, taps Send
2. Client sends via WebSocket (or POST if WS down)
3. Chat server validates, assigns message_id, persists to DB
4. Server ACKs sender → "sent" ✓
5. Server looks up recipient's active WebSocket connection
6. If online: push message → recipient ACKs → "delivered" ✓✓ to sender
7. Recipient opens chat → "read" ✓✓ blue to sender
8. If offline: message stays in DB; push notification via notification service

Chat system architecture

Critical rule: persist before ACK. If server crashes after ACK but before DB write, message is lost. Write to DB (or durable queue) first, then ACK sender.

Delivery state machine

         ┌──────────┐
         │ sending  │ (client optimistic UI)
         └────┬─────┘
              │ server ACK
         ┌────▼─────┐
         │  sent    │ ✓
         └────┬─────┘
              │ recipient device ACK
         ┌────▼─────┐
         │ delivered│ ✓✓
         └────┬─────┘
              │ recipient opens chat / read_receipt
         ┌────▼─────┐
         │   read   │ ✓✓ blue
         └──────────┘

Each state transition is a separate event — sender's UI updates via WebSocket push.

python

def on_message_received_by_device(message_id, recipient_id):
    db.update_delivery_state(message_id, recipient_id, "delivered")
    notify_sender(message_id, state="delivered")

def on_message_read(message_id, recipient_id):
    db.update_delivery_state(message_id, recipient_id, "read")
    notify_sender(message_id, state="read")

Group chat: track delivery state per participant per message. 53-member group = 53 rows in message_delivery table for one message.

Database schema

Conversations

sql

CREATE TABLE conversations (
  id            UUID PRIMARY KEY DEFAULT gen_random_uuid(),
  type          VARCHAR(10) NOT NULL CHECK (type IN ('direct', 'group')),
  title         VARCHAR(100),  -- group name; NULL for 1:1
  created_at    TIMESTAMP DEFAULT NOW()
);

Participants

sql

CREATE TABLE participants (
  conversation_id UUID NOT NULL REFERENCES conversations(id),
  user_id         BIGINT NOT NULL REFERENCES users(id),
  joined_at       TIMESTAMP DEFAULT NOW(),
  last_read_at    TIMESTAMP,  -- for unread badge
  PRIMARY KEY (conversation_id, user_id)
);

CREATE INDEX idx_participants_user ON participants(user_id);

Index on user_id — "list all conversations for this user."

Messages

sql

CREATE TABLE messages (
  id              BIGSERIAL PRIMARY KEY,
  conversation_id UUID NOT NULL REFERENCES conversations(id),
  sender_id       BIGINT NOT NULL REFERENCES users(id),
  body            TEXT NOT NULL,
  created_at      TIMESTAMP DEFAULT NOW()
);

CREATE INDEX idx_messages_conv_created ON messages(conversation_id, created_at DESC);

Message delivery (per-recipient state)

sql

CREATE TABLE message_delivery (
  message_id      BIGINT NOT NULL REFERENCES messages(id),
  recipient_id    BIGINT NOT NULL REFERENCES users(id),
  state           VARCHAR(20) NOT NULL DEFAULT 'sent'
                  CHECK (state IN ('sent', 'delivered', 'read')),
  updated_at      TIMESTAMP DEFAULT NOW(),
  PRIMARY KEY (message_id, recipient_id)
);

For 1:1 chat, sender is excluded from message_delivery — only the other participant gets a row.

API design

Send message (WebSocket frame)

json

{
  "type": "send_message",
  "conversation_id": "a1b2c3d4-...",
  "client_msg_id": "local-uuid-for-dedup",
  "body": "Happy Diwali! 🪔"
}

Server response:

json

{
  "type": "message_ack",
  "client_msg_id": "local-uuid-for-dedup",
  "message_id": 84729163,
  "state": "sent",
  "created_at": "2026-11-01T18:30:00Z"
}

client_msg_id lets the client deduplicate retries — tap Send twice on slow network should not create two messages.

Get message history (HTTP)

http

GET /api/v1/conversations/{id}/messages?limit=50&before=84729100
Authorization: Bearer <token>

Cursor-based pagination on created_at or message_id. User scrolls up → fetch older batch.

List conversations

http

GET /api/v1/conversations

Returns conversations sorted by last_message_at — denormalized column updated on each new message.

Group chat send flow
